1

2
import anysec
3
from anysec import Norm, DesignCode, LimitState
4
from anysec import StressStrainCurve
5
from anysec import Concrete, ReinforcementSteel, PrestressingSteel, MaterialType
6
from anysec import Point, Surface, Line, FiberGroup
7
from anysec import SectionOrigin, InteractionSurface, deformedParam, Section
8

9
from anysec_utils import plot_ssc, plot_section, plot_section_3d, plot_nmm, plot_nmm_, moment_curvature, _get_mc_data
10

11
# Define design code
12
EN_199X_200X = DesignCode(Norm.EN_199X_200X, "EN_199X_200X")
13

14
# Define materials
15
conc_45 = Concrete(code=EN_199X_200X, curveType=CurveType.PR, title="Concrete C45", strength_class=45, color='lightgrey')
16
stee_B500B = ReinforcementSteel(code=EN_199X_200X, curveType=CurveType.BLF, title="Reinforcement steel B500B", strength_class=500, color='blue')
17

18
# Define a rectangular section
19
## Define a concrete surface
20
rec_surf = Surface(
21
    points=[
22
		Point(yz=Coordinates(0.0, 0.0)), Point(yz=Coordinates(300.0, 0.0)),
23
		Point(yz=Coordinates(300.0, 700.0)), Point(yz=Coordinates(0.0, 700.0))
24
	],
25
    material=conc_45
26
)
27

28
## Define reinforcement
29
rec_fg = FiberGroup(
30
    points=[
31
        Point(yz=Coordinates(50.0, 50.0), value=25.0, is_circle=True, preload=0.0),
32
		Point(yz=Coordinates(250.0, 50.0), value=25.0, is_circle=True, preload=0.0),
33
		Point(yz=Coordinates(50.0, 650.0), value=25.0, is_circle=True, preload=0.0),
34
		Point(yz=Coordinates(250.0, 650.0), value=25.0, is_circle=True, preload=0.0)
35
    ],
36
    material=stee_B500B,
37
    matrix=rec_surf
38
)
39

40
## Create section object
41
beam300x700 = Section(surfaces=[rec_surf], fiber_groups=[rec_fg], lines=[], origin=SectionOrigin.ELASTIC_CENTER)
42

43
# Cache capacity interaction surfaces for given limit states
44
beam300x700.cache_interaction(limitStates=[LimitState.ULS], n_range_size=15, angle_step=45, theta=True)
45

46
# Get capacity for a given applied force vector (NEd, MyEd, MzEd)
47
fEd = FV(0.0, -16000, 500)
48
fRd = beam300x700.get_capacity(LimitState.ULS, fEd)
49

50
# Get moment-curvature data for a given axial force NEd and a Neutral axis orientation θ
51
beam300x700.get_curvature(N=-1000.0, theta=math.radians(30.0), limitState=LimitState.ULS, step=1e-4, until_collapse=True)
52
